An innovative durable dry (oil-free) pumps, NeoDry Series, which are products of Kashiyama Industries Ltd. are available in the UK market. This innovative non-contact mechanism provides unrivaled 6 years maintenance cycle and reduces your cost of ownership. NeoDry series are available in 7 different pumping speeds between 250 L/min and 5,000 L/min.
- Clean multi-stage roots pump
- no oil vapour, no particle generation, no PTFE tip seal dust
- Unmatched High-Vacuum performance at all pressure range
- continuous operation at atmospheric pressure
- Easy to Install and user friendly design
- small footprint and consistently low noise and low vibration
- Any average of 6 years maintenance free operation for clean gas usage
- performance of our pump over 10 years on the market based on a review of our records
- Optimal backing pump for UHV applications
- low base pressure, high compression for light gases
- High water vapour capacity of up to 600g/h
- and optional special coated version for chemical resistance
- Various choice with market-proven reliability
- 7 models from 7 to 300m3/h with high reliability for a variety of systems
| Specification | NeoDry7E | NeoDry15E | NeoDry30E | NeoDry36E | NeoDry60E | NeoDry100E | NeoDry300E |
| Max. pumping speed | 110 L/min (7 m3/h) | 250 L/min (15m3/h) | 500 L/min (30 m3/h) | 600 L/min (36 m3/h) | 1,000L/min (60 m3/h) | 1,670L/min (100m3/h) | 5000 L/min (300 m3/h) |
| Ultimate Pressure (with no gas ballast) | 5.0 Pa (1.0 x 10-2 mbar] | 1.0 Pa (1.0 x 10-2 mbar) | 2.0 Pa (0.02mbar) | 0.5 Pa (5.0 x 10-3 mbar) | |||
| Main power (50/60Hz) | 1 Phase AC200~240V | ||||||
| Gas Ballast | Standard Accessory | ||||||
| Max. allowable moisture (with gas ballast) | 120 g/h | 250 g/h | 350 g/h | 600 g/h | |||
| Noise level (when the inlet closed) | ≤ 56 dB(A) | ≤ 58 dB | ≤ 60 dB | ≤ 55 dB | ≤ 72 dB | ||
| Vibration (when the inlet closed) | ≤ 8 µmp-p | ≤ 15 µmp-p | |||||
| Weight | 19 kg | 23 kg | 25 kg | 54 kg | 56 kg | 90 kg | 125 kg |
| Inlet port | NW25 | NW40 | NW50 | ||||
| Outlet Port | NW25 | ||||||
| Outline Dimensions, mm | 196 x 219 x 360 | 210 x 250 x 385 | 210 x 250 x 410 | 298 x 275 x 475 | 315 x 275 x 530 | 320x365x576 | 304 x 575 x 574 |
| Safety standard | CE Marking, NRTL(UL 61010-1, CAN/CSA C22.2 No.61010-1) | ||||||
S-P Curvce
