All the advantages of the NeoDry series but even quieter, more user-friendly, and suitable for a variety of applications.
Premium Features
- Extremely low noise, 45dB(A) or less
- Wide voltage range, 1Ph AC100-240V, auto-switching
- Remote control interface
- I/O input, Serial communication (RS485)
- LED indicator for pump status
- Special seal material for solvent/condensable gas
- Isolation valve power source
- Flow controllable gas ballast valve (air/N2)
- EU harmonic emission compliant
LED indicator for pump status
10% more water vapour tolerance (vs E series)
Inherited benefits from NeoDry E series
- Clean multi-stage roots pump
- No oil vapour, no particle generation, no tip-seal dust
- An average of 6 years maintenance-free operation
- for clean/dry gas usage based on records
- High vacuum performance at all pressure ranges
- Continuous operation for atmospheric pressure
- Optimal backing pump for UHV application
- Low base pressure, high compression for light gases
Standard models
| Spec. / Products | NeoDry7G | NeoDry15G | NeoDry30G | NeoDry36G |
|---|---|---|---|---|
| Max. pumping speed, L/min | 110 | 250 | 500 | 600 |
| Ultimate pressure, mbar (Pa) With no gas ballast | 5.0x10-2 (5.0) | 1.0x10-2 (1.0) | 1.0x10-2 (1.0) | 7.0x10-3 (0.7) |
| Supply voltage, V | Single phase, AC100-240V, 50/60Hz, auto-switching | |||
| Gas ballast mechanism | Optional (flow control gas ballast ) | |||
| Max. allowable moisture, g/h | 135 | 275 | 275 | 350 |
| Typical noise value*, dB(A) | ≤45 | ≤51 | ||
| Vibration at inlet, µm p-p | ≤8 | |||
| Weight (approx.), kg | 19 | 22 | 24 | 51 |
| Inlet | NW25 | NW40 | ||
| Outlet | NW25 | |||
| Power consumption, kW (at ultimate pressure) | 0.28 | 0.34 | 0.55 | |
| Dimensions W x H x L | 360x196x196 | 385x210x219 | 410x210x219 | 475x298x260 |
| Safety standards | NRTL (UL61010-, CAN/CSA C22.2 No 61010-1), CE Marking, UKCA, KC | |||
S-P Curve
Silencers
| Item | Applicable model | Part number |
|---|---|---|
| SR-60 (Horizontal) in-line pipe type | All | 27910-22850 |
| SR-28-2 (vertical) in-line pipe type | All | 27910-22101 |
| EFS-11 Filter type | 7G, 15G | 27102-10390 |
| EFS00001002 Filter type | 30G | 17102-10410 |
